Isolation Transformer

Dubas manufactures wide range of isolation transformers. These transformers insulate the customers load from most of the electrical noises, harmonics, and spikes etc.

Dubas isolation transformers are available in small ratings to 400KVA rating, in air cooled and oil cooled constructions. The transformers are also available in 1ph / 1 Ph, 3 Ph / 3 Ph and also in 3 Ph / 1 Ph formats.

Apart from direct load protections, dubas IT is employed as a reliable Bypass source for the bypass power conditioning of UPS System installations.

FEATURES:

• Wide range of selection from 1 KVA to 400 KVA
• Built with all copper windings and conductors.
• Both Air cooled and oil cooled versions available
• Various input voltage and output voltage configuration options in single phase, two phase or three phases.
• Available for 50 Hz, 60 Hz, 400 Hz or for high frequency applications.
• IP 00 to IP 65 construction models.
• Custom built protections.
• Multiple tapping options at the input and output.
• Can be integrated into dubas Servo Stabilizers and offered in single cubicle.
• Highly efficient, up to 98%.
• Designed for linear and non-linear loads
• Double wound shielded for high common mode noise attenuation.
• High transverse mode noise attenuations.
• Full load testing capability at the factory.
