K –Rated Transformer
Dubas manufacturers wide range of K-Rated Isolation Transformers for protecting the loads from various type of power problems like electrical noises, harmonics, spikes etc.,
Many of the loads are of non-linear type and create high distortions in the current waveforms. Harmonics generate higher heat in the transformer. A transformer built to handle these harmonic currents is rated by K factor. K factor isolation transformers can handle these harmonic currents without exceeding the specified temperature rise levels. Typically, K-13 transformers are employed in many applications
FEATURES:
- Wide range of selection from 1 KVA to 400 KVA
- Built with all copper windings and conductors.
- Both Air cooled and oil cooled versions available
- Various input voltage and output voltage configuration options in single phase, two phase or three phases.
- Available for 50 Hz, 60 Hz, 400 Hz or for high frequency applications.
- IP 00 to IP 65 construction models.
- Custom built protections.
- Multiple tapping options at the input and output.
- Can be integrated into dubas Servo Stabilizers and offered in single cubicle.
- Highly efficient, up to 98%.
- Designed for linear and non-linear loads
- Double wound shielded for high common mode noise attenuation.
- High transverse mode noise attenuations.
- Full load testing capability at the factory.
