G7i-31 SERIES
G7i Series of UPS is one of the most reliable UPS System for the Industrial application, with customizable architecture on the famed GX series platform. The system is designed and built for reliability as the primary feature of the system. G7i series has an absolute capability to customize as per the application requirement with systems adept even for IP 65 constructions or seismic tests.
The system employs IGBT based PWM converter for Rectifier / battery Charger as well for the Inverter. System is modularly built and has the advantage of building to meet any space limitations at sites. The systems can be configured to suit site criticality with critical – non critical loading options, hot standby options or seamless paralleling. The system has an adaptable DCV window which provides excellent flexibility to choose battery combinations.
FEATURES:
- State of the art technology employing PWM for both AC-DC and DC-AC conversion with DSP based Digital Control
- Function block based Independent processor
- Built in output Isolation Transformer for Galvanic isolation and optional input isolation transformer
- Modular and compact construction
- Application based DCV choice & Battery type
- High Short circuit current handling capability
- Seismically qualified and tested models for Nuclear installations
- System can be built to suit the application demanding rating and configurations.
- Seamless paralleling and customized configurations
